Introduction

Ming Zheng Hong Electronics is proud to introduce its cutting-edge 24-layer high frequency rigid PCB (FR-4), specifically engineered for the telecommunications industry. This product guarantees high precision signal transmission and superior processing quality, essential for reliable communication.

Key Features

This 24-layer PCB utilizes Isola 370HR materials, known for their excellent electrical performance in high frequency applications. Enhanced with ENIG surface treatment, our PCBs ensure reliable solder joints and long-term oxidation resistance.

The design supports both 50 Ohm single-ended and 100 Ohm differential impedance control, ensuring the consistency and accuracy of signal transmission, which is critical for modern telecommunication systems.

Manufacturing Standards

Our manufacturing process adheres strictly to IPC, RoHS, and REACH international standards, ensuring that all products meet stringent quality requirements. Advanced automated optical inspection (AOI) is used in our manufacturing, confirming that each PCB is defect-free, providing clients with peace of mind.

With accurate thickness control (1.6mm±0.16mm) and copper thickness (1 oz for outer layers and 0.5 oz for inner layers), our PCBs are tailored for intricate electrical demands.

Applications

Our 24-layer high frequency rigid PCBs are ideal for various applications including core telecom equipment like base stations, routers, and switches, where high signal stability and dense circuit layouts are crucial. They also suit enterprise-grade servers and storage systems that require high signal integrity.

Moreover, they meet the emerging demands of 5G technologies, making our products essential for both infrastructure and ancillary devices needing robust high-frequency signal processing.
